| Tools: | 12mm Wrench |
| 13mm Wrench |
| Materials: | 2 Sachs Gas Charged Lift Supports (SG329001) |
Installation:
| 1. | First it helps to have a friend support the hood, otherwise you have to hold it up with your shoulder. |
| 2. | Using the 12mm wrench remove the lower bolt, connecting the strut to the body. |
| 3. | Using the 12mm wrench loosen the upper bolt, connecting the strut to the hood, until you can loosen it with your fingers. |
| 4. | Holding the strut with one hand remove the upper bolt. |
| 5. | Install the short ball joint into the hood and tighten it in with the 13mm wrench. |
| 6. | Install the long ball joint into the body and tighten it in with the 13mm wrench. |
| 7. | Snap the strut in, one end at a time, the same way the original one was, thicker side connected to the hood. |
| 8. | Repeat with the other side. |
